VHD Delta Wing Orchard Mowers


VHD Delta Wing Orchard Mowers are designed to be a multi-tasking machine for Contractors and orchardists requiring an industrial strength machine with a narrow road transport width of 2.5m.

Mulch throw both sides with discharge deflectors or lift full side plates for discharge and mulching of small to medium size prunings <50mm

The name says it all, VHD stands for “Very Heavy Duty”. The VHD mowers come with the 205HP Comer gearbox driveline and PTO shaft along with heavy duty 13mm blades. This ensures it is built to survive and ideal for operation in commercial orchards.

Suitable for 90 to 200HP Tractors (subject to compatible Tractor specifications).


Base Features:

  • 4.57m – 6.10m cutting widths
  • 6mm fully welded, easy clean deck with 8mm side plates
  • 210HP Comer 1:1 gearbox driveline with 20 spline input shaft
  • Comer V80 series CVJ PTO Shaft
  • Over-run device on input and 4 plate clutches on each V80 PTO to the rotor heads (3)
  • Front and rear safety debris chains
  • 8mm Removable full sides for rear discharge, and adjustable side discharge deflector with front anti-scalp skids for under tree mulch throw
  • Heavy duty tow pull including shock absorbing linkage connection
  • Heavy duty flotation tyres 10/75-15.3 18 PLY


Optional Features:

  • Dual mulching blade for a finer breakdown of long materials
  • Oil seal protector kit
